Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 141: As a positively charge rod is brought nearer to the top cap of a positively charged gold leaf electroscope, the divergence of the leaves will Options:
  A) decrease to zero
  B) steadily increase
  C) decrease to zero and then increase
  D) remain constant
  E) increase to a maximum and then decrease
  Show Answer
  The correct answer is B .
• Question 142: A temperature scale has a lower fixed point of 40mm and a upper fixed point of 200mm. What is the reading on this scale when a thermometer reads 60^oC? Options:
  A) 33.3mm
  B) 36.0mm
  C) 96.0mm
  D) 136.0mm
  Show Answer
  The correct answer is D .
• Question 143: A machine whose efficiency is 60% has a velocity ratio of 5. If a force of 500N is applied to lift a load P, what is the magnitude of P? Options:
  A) 1500N
  B) 500N
  C) 4166N
  D) 750N
  Show Answer
  The correct answer is A .
• Question 144: When taking a penalty kick, a footballer applies a force of 30.0N for a period of 0.05s. if the mass of the ball is 0.075kg, calculate the speed with which the ball moves off. Options:
  A) 4.50ms^-1
  B) 11.25ms^-1
  C) 20.00ms^-1
  D) 45.00ms^-1
  Show Answer
  The correct answer is C .
• Question 145: A clinical thermometer is different from other mercury in glass thermometers owing to Options:
  A) the constriction on its stem
  B) the grade of mercury used in it
  C) its long stem
  D) its wide range of temperatures
  Show Answer
  The correct answer is A .
• Question 146: The velocity of a sound wave at 27^oC is 360ms^-1. Its velocity at 127^oC is Options:
  A) 120√3 ms^-1
  B) 240 ms^-1
  C) 240√3 ms^-1
  D) 720√3 ms^-1
  Show Answer
  The correct answer is C .
• Question 147: The optical instrument which is suitable for viewing a nearby objects is ………..? Options:
  A) Telescope
  B) sextant
  C) microscope
  D) periscope
  Show Answer
  The correct answer is C .
• Question 148:

  The relationship between the coefficient of linear expansion $\alpha$ and volumetric expansion ($\gamma$) is-----------------

  Options:
  A) $\gamma$ = ${\alpha }^{-3}$
  B) $\gamma$ = $\alpha$
  C) 3$\alpha$
  D) $\gamma$ = ${\alpha }^3$
  Show Answer
  The correct answer is C .
• Question 149: A quantity of water at 0°C is heated to about 30°C. At each degree rise in temperature, its density will Options:
  A) rise steadily
  B) fall steadily
  C) fall then rise
  D) rise then fall
  Show Answer
  The correct answer is D .
• Question 150:

  Which of the units of the following physical quantities are derived?

  I. Area
  II. Thrust
  III. Pressure
  IV. Mass

  Options:
  A) I, II, III and IV
  B) I, II, and III only
  C) I, II, and IV only
  D) I and IV only
  Show Answer
  The correct answer is B .
