• Question 41:


  Two mirrors of the same length are arranged as shown in the diagram. A ray of light NO strikes the system at O and emerges along PQ. The emergent ray has been deviated through

  Options:
  A) 220${}^o$
  B) 200${}^o$
  C) 210${}^o$
  D) 180${}^o$
  Show Answer
  The correct answer is D .
• Question 42: If the mechanical advantage of a machine is 4. What is its ratio for LOAD to EFFORT? Options:
  A) 4:01
  B) 1:04
  C) 5:01
  D) 2:01
  Show Answer
  The correct answer is A .
• Question 43: A piece of substance of specific head capacity 450JKg^-1K^-1 falls through a vertical distance of 20m from rest. Calculate the rise in temperature of the substance on hitting the ground when all its energies are converted into heat. [g = 10ms^-2] Options:
  A) 2/9°C
  B) 4/9°C
  C) 9/4°C
  D) 9/2°C
  Show Answer
  The correct answer is B .
• Question 44:

  Light of wavelength 589 nm in vacuum passes through a piece of fused quartz of index of refraction n = 1.458. What is the frequency of the light in fused quartz?

  [Speed of light c = $3.00\times {10}^{8}m{s}^{-1}$]

  Options:
  A) $5.09\times {10}^{15}$Hz
  B) $5.09\times {10}^{14}$ Hz
  C) $1.77\times {10}^{15}$ Hz
  D) $1.77\times {10}^{14}$ Hz
  Show Answer
  The correct answer is B .
• Question 45:

  Calculate the absolute pressure at the bottom of a lake at a depth of 32.8 m. Assume the density of the water is 1 x 10^3 kgm-3 and the air above is at a pressure of 101.3 kPa.

  [Take g = 9.8 ms-2]

  Options:
  A) 422.7
  B) 220.14
  C) 464.53
  D) 321.74
  Show Answer
  The correct answer is A .
• Question 46:

  What is the name of the model of the atom that describes electrons as orbiting the nucleus in specific energy levels?

  Options:
  A) Bohr model
  B) Dalton model
  C) Rutherford model
  D) Thomson model
  Show Answer
  The correct answer is A .
• Question 47:



  PQ is a thin rod on a horizontal table, RS is a plane mirror inclined at ${45}^{\circ }C$ to the horizontal as shown above. The image of PQ as seen in the mirror by the eye T is

  Options:
  A) horizontal
  B) parallel to the mirror
  C) at infinity
  D) vertical
  E) highly magnified
  Show Answer
  The correct answer is B .
• Question 48:

  The linear expansivityof brass is 2 x 10${}^{-5}$ ${}^o{C}^{-1}$. If the volume of piece of brass is 10cm${}^3$ at 0${}^o$C. What will be its volume at 100${}^o$C?

  Options:
  A) 10.06cm${}^3$
  B) 10.04 cm${}^3$
  C) 10.02 cm${}^3$
  D) 10.20 cm${}^3$
  Show Answer
  The correct answer is A .
• Question 49:

  A piece of substance of specific heatcapacity 450Jkg${}^{-1}$k${}^1$ falls through a vertical distance of 20m from rest. Calculate the rise in temperature of the substance on hitting the ground when all its energies are converted into heat. [g = 10ms${}^{-2}$]

  Options:
  A) $\frac{2}{9}$ºC
  B) $\frac{4}{9}$ºC
  C) $\frac{9}{2}$ºC
  D) $\frac{9}{4}$ºC
  Show Answer
  The correct answer is B .
• Question 50: A parallel plate capacitor has a common plate area of 5 x 10^-8m² and plate separation of 2 x 10³m, Assuming free space, What is the capacitance? [$\epsilon$_o = 9.0 X 10^-12C²N^-1m^-2] Options:
  A) 2.25 x 10^-17F
  B) 4.50 x 10^-17F
  C) 2.25 x 10^-16F
  D) 4.50 x 10^-16F
  Show Answer
  The correct answer is C .
