Physics Exam Past Questions and Answers | JAMB, WAEC and NECO

Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 921: A simple pendulum, 0.6m long, has a period of 1.5s. What is the period of a similar pendulum of 0.4m length in the same location? Options:
  A) $1.5\frac{\sqrt{2}}{3}$s
  B) $1.5\frac{\sqrt{3}}{2}$s
  C) 2.25s
  D) 1.00s
  E) 2.00s
  Show Answer
  The correct answer is A .
• Question 922: Two forces of magnitudes 7N and 3N act at right angles to each other. The angle $\theta$ between the resultant and the 7N force is given by Options:
  A) cos$\theta$ = $\frac{3}{7}$
  B) sin$\theta$ = $\frac{3}{7}$
  C) tan$\theta$ = $\frac{3}{7}$
  D) cot$\theta$ = $\frac{3}{7}$
  Show Answer
  The correct answer is C .
• Question 923: In photoelectric effect, electrons will leave the metal surface when illuminated by light of appropriate frequency if the photon energy is Options:
  A) greater than the work function
  B) less than the work function
  C) equal to the work function
  D) equal to the maximium kinetic energy of the electron
  Show Answer
  The correct answer is A .
• Question 924:

  Which of the following conditions are necessary and sufficient for total internal reflection to take place at the boundary between two optical media?

  I. Light is passing from optical denser medium to optically less dense medium

  II. Light is passing from optically less dense medium to optically denser medium

  III. Angle of incidence is greater than a certain critical value

  IV. Angle of incidence is lesser than a certain critical value

  Options:
  A) I and II only
  B) II only III only
  C) III and IV only
  D) I and III only
  Show Answer
  The correct answer is D .
• Question 925: Which of the following statements are true about the spring balance and the chemical balance? i. both are used to measure the mass of an object. ii. either of them may be used to measure the weight of an object. iii. the spring balance works on the principle of Hooke's law while the chemical balance works on the principle of moments. iv. a change in gravity does the readings of a spring balance but not that of a chemical balance. Options:
  A) i, and iv
  B) ii and iii
  C) ii and iv
  D) i, ii and iii
  E) i and iii
  Show Answer
  The correct answer is C .
• Question 926:

  Calculate the heat energy required to vaporize 50g of water initially at 80ºCif the specific heat capacity of water is 4.23jg${}^{-1}$k${}^{-1}$ (specific latent heat of vaporization of water is 2260jg${}^{-1}$

  Options:
  A) 530000J
  B) 23200J
  C) 17200J
  D) 130000J
  Show Answer
  The correct answer is D .
• Question 927:



  The diagram above shows a velocity - time graph. The statement that is true about this motion is that the car

  Options:
  A) has no acceleration between point F and G
  B) decelerates between F and H
  C) has a constant soeed between points E and F
  D) Accelerates between points F and G
  Show Answer
  The correct answer is A .
• Question 928: A rocket burns fuel at the rate of 10kgs^-1 and ejects it with velocity of 5 x 10³ms^-1. The thrust exerted by the gas on the rock is Options:
  A) 2.5 x 10⁷N
  B) 5.0 x 10⁴N
  C) 5.0 x 10²N
  D) 2.0 x 10^-3N
  Show Answer
  The correct answer is B .
• Question 929: As the pressure of a fluid increases, its viscosity Options:
  A) decreases
  B) increases
  C) increases then decreases
  D) remains constant
  Show Answer
  The correct answer is B .
• Question 930: A uniform meter rule weighing 0.5N is to be pivoted on a knife-edge at the 30cm-mark. where will a force of 2N be placed from the pivot to balance the meter rule? Options:
  A) 95cm
  B) 25cm
  C) 20cm
  D) 5cm
  Show Answer
  The correct answer is B .
