Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 661:



  In the series a.c circuit shown above, the p.d across the inductor is 8V_r.m.s and that across the resistor is 6V_r.m.s. The effective voltage is

  Options:
  A) 2V
  B) 10V
  C) 14V
  D) 48V
  Show Answer
  The correct answer is B .
• Question 662: During a thunderstorm, the sound is heard over a long time. this phenomenon is referred to as Options:
  A) diffraction of sound
  B) refraction of sound
  C) superposition
  D) reveraberation
  Show Answer
  The correct answer is D .
• Question 663: Find the work done in moving a 2 C charge between two points X and Y in an electric field if the potential difference is 100 volts Options:
  A) 50J
  B) 100J
  C) 200J
  D) 400J
  Show Answer
  The correct answer is C .
• Question 664: The direction of the path taken by light is called Options:
  A) Locus
  B) Lines
  C) Ray
  D) Beam
  Show Answer
  The correct answer is C .
• Question 665: What is the cost of running seven 40 W lamps and five 80 W la mps for 12 hours of the electrical energy cost N7.00kWk? Options:
  A) N80.00
  B) N45.36
  C) N65.00
  D) N57.12
  Show Answer
  The correct answer is D .
• Question 666: Two bodies have masses in the ratio 3:1. They experience forces which impart to them acceleration in the ratio 2:9 respectively. Find the ratio of forces the masses experienced. Options:
  A) 1 : 4
  B) 2 : 1
  C) 2 : 3
  D) 2 : 5
  Show Answer
  The correct answer is C .
• Question 667:



  A force varying linearly with the distance acts on a body as shown above, The work done on the body by the force during the first 10m of motion is

  Options:
  A) 100J
  B) 150J
  C) 200J
  D) 300J
  E) 600J
  Show Answer
  The correct answer is A .
• Question 668: Why do soldiers march disorderly while crossing a bridge? Options:
  A) To prevent resonance on the bridge
  B) To set the bridge into resonance
  C) To make the b ridge collapse
  D) To spread their weight evenly on the bridge
  Show Answer
  The correct answer is A .
• Question 669: The temperature gradient across a copper rod of thickness 0.02m, maintained at two temperature junctions of 20°C and 80°C respectively is Options:
  A) 3.0 x 10²Km^-1
  B) 3.0 x 10³Km^-1
  C) 5.0 x 10³Km^-1
  D) 3.0 x 10⁴Km^-1
  Show Answer
  The correct answer is B .
• Question 670:

  The inner diameter of a test tube can be measured accurately using a?

  Options:
  A) micrometer screw gauge
  B) pair of dividers
  C) meter rule
  D) pair of vernier calipers
  Show Answer
  The correct answer is D .
