Physics Exam Past Questions and Answers | JAMB, WAEC and NECO

Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 421:

  The slope of the straight line displacement-time graph indicates?

  Options:
  A) distance traveled
  B) uniform velocity
  C) uniform acceleration
  D) uniform speed
  Show Answer
  The correct answer is B .
• Question 422: Which of the following features is NOT a characteristic of natural radioactivity? Options:
  A) Radioactivity is a nuclear phenomenon
  B) Radioactivity is exhibited only by elements of mass number greater than 206
  C) The radioactivity of an element is affected by electric and magnetic fields in the surroundings
  D) Radioactive substances emits three types of radiations, a-rays, $\beta$-rays and y-rays
  E) The radioactive element is transformed into a new element
  Show Answer
  The correct answer is B .
• Question 423: If a pump is capable of lifting 5000kg of water through a vertical height of 60m in 15 min, the power of the pump is Options:
  A) 2.2.5 x 10 ⁵js^-1
  B) 2.5 x 10⁴js^-1
  C) 3.3 x 10³js^-1
  D) 3.3 x 10²js^-1
  Show Answer
  The correct answer is C .
• Question 424:



  The figure above shows displacement-time graphs for three different motions. which of the following statements is correct

  Options:
  A) graph 2 corresponds to the highest velocity
  B) graph 1 corresponds to zero gravity
  C) graph 3 corresponds to a particle moving in the negative x direction
  D) graph 2 corresponds to a particle moving in the positive x direction
  Show Answer
  The correct answer is D .
• Question 425: Which of the following best describes the energy changes which take place when a steam engine drives a generator which lights a lamp? Options:
  A) heat $\to$ light $\to$ sound $\to$ kinetic
  B) kinetic $\to$ light $\to$ heat $\to$ electricity
  C) heat $\to$ kinetic$\to$ electricity $\to$ heat $\to$ light
  D) electricity $\to$ kinetic $\to$ heat v light
  E) heat $\to$ sound $\to$ kninetic v electricity
  Show Answer
  The correct answer is C .
• Question 426: The number of neutrons contained in the nucleus ${}_{92}^{238}U$ is Options:
  A) 92
  B) 146
  C) 238
  D) 330
  Show Answer
  The correct answer is B .
• Question 427:

  An alternating current can induce voltage because it has

  Options:
  A) ripple value
  B) varying magnetic field
  C) weaker magnetic field than direct current
  D) high peak value
  Show Answer
  The correct answer is B .
• Question 428: Radio waves belong to the class of wave whose velocity is about Options:
  A) 34m/s
  B) 3 ×10⁶m/s
  C) 3 ×10⁸m/s
  D) 3 × 10^-8m/s
  Show Answer
  The correct answer is C .
• Question 429: The phenomenon of light bending round an obstacle is? Options:
  A) diffraction
  B) refraction
  C) reflection
  D) polarization
  Show Answer
  The correct answer is A .
• Question 430: A liquid-in-glass thermometer should quickly register temperature changes. This is achieved by choosing a liquid that Options:
  A) is opaque
  B) has high density
  C) has regular expansion
  D) has a high thermal conductivity
  E) can wet glass
  Show Answer
  The correct answer is D .
