Physics Exam Past Questions and Answers | JAMB, WAEC and NECO

Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 201: A solid weigh 10 .00 N in air, 6 N when fully immersed in water and 7 . 0 N when fully immersed in a liquid X. Calculate the relative density of the liquid, X. Options:
  A) 5/3
  B) 4/3
  C) 3/4
  D) 7/10
  Show Answer
  The correct answer is C .
• Question 202:



  The diagram above shows a velocity - time graph. The statement that is true about this motion is that the car

  Options:
  A) has no acceleration between point F and G
  B) decelerates between F and H
  C) has a constant soeed between points E and F
  D) Accelerates between points F and G
  Show Answer
  The correct answer is A .
• Question 203: Which of the following is a semiconductor Options:
  A) copper
  B) silicon
  C) plastic
  D) Iron
  Show Answer
  The correct answer is B .
• Question 204:



  The diagram above shows two wave forms P and Q at a particular instant in time. the two waves will interface

  Options:
  A) destructively to produce a wave of larger amplitude
  B) destructively to produce a wave of smaller amplitude
  C) constructively to produce a wave of larger amplitude
  D) constructively to produce a wave of smaller amplitude
  Show Answer
  The correct answer is C .
• Question 205:

  Dry

  Day 1 - 30°C | Day 2 - 29°C | Day 3 - 25°CWet

  Day 1 - 22°C | Day 2 - 22°C | Day 3 - 21°CThe reading above are for three consecutive days from a wet and dry bulb hygrometer. It can be concluded that the relative humidity for the three days

  Options:
  A) decreased steadily
  B) remained unchanged
  C) increased steadily
  D) was least on Day 1
  Show Answer
  The correct answer is C .
• Question 206: Power supply is transmitted at a very high voltage and low current in order to Options:
  A) make pass through the trasformers
  B) increase the power supply
  C) make it travel fast
  D) prevent overheating of the coil
  Show Answer
  The correct answer is D .
• Question 207: If the force and the velocity on a system are each reduced simultaneously by half, the power of the system is Options:
  A) doubled
  B) reduced to a quarter
  C) reduced by half
  D) constant
  Show Answer
  The correct answer is B .
• Question 208: The amount of heat needed to raise the temperature of 10kg of copper by 1k is its Options:
  A) specific heat capacity
  B) heat capacity
  C) latent heat
  D) internal energy
  Show Answer
  The correct answer is B .
• Question 209:

  A ball of mass 0.1kg is thrown vertically upwards with a speed of 10ms${}^{-1}$ from the top of a tower 10m high. Neglecting air resistance, its total energyjust before hitting the ground is? (Take g = 10ms${}^{-2}$)

  Options:
  A) 5J
  B) 10J
  C) 15J
  D) 20J
  Show Answer
  The correct answer is C .
• Question 210: If two inductors of inductances 3H and 6H are arranged in series, the total inductance is Options:
  A) 9.0H
  B) 18.0H
  C) 0.5H
  D) 2.0H
  Show Answer
  The correct answer is A .
