Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 11:


  A 400 N box is being pushed across a level floor at a constant speed by a force P of 100 N at an angle of 30.0° to the horizontal, as shown in the the diagram below. What is the coefficient of kinetic friction between the box and the floor?

  Options:
  A) 0.19
  B) 0.24
  C) 0.40
  D) 0.22
  Show Answer
  The correct answer is A .
• Question 12: A Motor Tyre is inflated to pressure of 2.0 x 10⁵Nm^-2 when the temperature of air is 27^oC. What will be the pressure in it at 87^oC assuming that the volume of the Tyre does not change? Options:
  A) 2.6 x 10⁵Nm^-2
  B) 2.4 x 10⁵Nm^-2
  C) 2.2 x 10⁵Nm^-2
  D) 1.3 x 10⁵Nm^-2
  Show Answer
  The correct answer is B .
• Question 13: What is the difference in the amount of heat given out by 4kg of steam and 4kg of water when both are cooled from 100^oC to 80^oC? [the specific latent heat of steam is 2,260,000Jkg^-1, specific heat capacity of water is 4200Jkg^-1K^-1] Options:
  A) 4200J
  B) 2,260,OOOJ
  C) 9,040,000J
  D) 9,380,000J
  Show Answer
  The correct answer is C .
• Question 14:

  Which of the following statements regarding the application of electrical conduction via gases is/are correct?
  Electrical conduction in gas is applied in:
  (i) The identification of gases
  (ii) Lighting/fluorescent tubes
  (iii) Photocells
  (iv) Cathode ray oscilloscope/T.V. tubes

  Options:
  A) (i), (iii) and (iv) only
  B) (i), (ii) and (iv) only
  C) (ii), (iii) and (iv) only
  D) (i), (ii) and (iii) only
  Show Answer
  The correct answer is B .
• Question 15:



  The figure above shows three capacitors, 2μF, 3μF and 6μF connected in series. If the p.d across the system is 12V, the p.d, across the 6μF capacitor is

  Options:
  A) 4V
  B) 12V
  C) 2V
  D) 6V
  Show Answer
  The correct answer is C .
• Question 16: A heating coil rated at 100W is used to boil off 0.5kg of boiling water. The time taken to boil off the water is [specific latent heat of vaporization of water = 2.3 x 10⁶Jkg^-1] Options:
  A) 1.15 x 10⁹ s
  B) 1.15 x 10⁷ s
  C) 1.15 x 10⁵ s
  D) 1.15 x 10⁴ s
  Show Answer
  The correct answer is D .
• Question 17:

  In an AC circuit, resonance occurs when the impedance of the circuit is:

  Options:
  A) Zero
  B) Maximum
  C) Equal to the capacitive reactance of the circuit
  D) Minimum
  Show Answer
  The correct answer is D .
• Question 18:



  Two mirrors M1 and M2 are inclined at right angles as shown above calculate the angle of reflection of the ray of light at M2

  Options:
  A) ${30}^{\circ }$
  B) ${45}^{\circ }$
  C) ${60}^{\circ }$
  D) ${90}^{\circ }$
  Show Answer
  The correct answer is C .
• Question 19: The instrument that measures both ac and dc is called Options:
  A) A current balance
  B) a moving coil ammenter
  C) a moving iron ammeter
  D) an inverter
  Show Answer
  The correct answer is C .
• Question 20: Calculate the escape velocity of a satellite launched from the earth's surface if the radius of the earth is 6.4x10⁶m Options:
  A) 25.3kms^-1
  B) 4.2kms^-1
  C) 4.0kms^-1
  D) 11.3kms^-1
  Show Answer
  The correct answer is D .
