Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 1981: What is the acceleration due to gravity 'g' on the moon, if g is 10^-2 on the earth? Options:
  A) 0. 10 ms^-2
  B) 0.74ms^-2
  C) 1.6ms^-2
  D) 10.00ms^-2
  Show Answer
  The correct answer is C .
• Question 1982:



  In a light experiment with a convex lens a student plotted a graph as shown above of the reciprocal of object distance (1)/u against the reciprocal of image distance (1)/v . the focal length of the lens is given as

  Options:
  A) slope of line PQ
  B) Reciprocal of either OP or OQ
  C) Length OP or OQ
  D) area under the graph E ratio OP/OQ
  Show Answer
  The correct answer is B .
• Question 1983:

  A tuning fork having a frequency of 312 Hz emits a wave which has a wavelength of 1.10 m. Calculate the velocity of sound

  Options:
  A) 312.0 ms${}^{-1}$
  B) 110.0 ms${}^{-1}$
  C) 343.2 ms${}^{-1}$
  D) 686.4 ms${}^{-1}$
  Show Answer
  The correct answer is C .
• Question 1984: A household refrigerator is rated 200 watts. If electricity costs 5k per kWh, what is the cost of operating it in 20 days? Options:
  A) N4.80
  B) N48.00
  C) N480.00
  D) N4800.00
  Show Answer
  The correct answer is C .
• Question 1985:



  The figure above shows a block of mass m sliding down a rough inclined plane QP at angle $\theta$ . The forces acting on the block along QP are

  Options:
  A) mg sinθ and the normal reaction
  B) mg sinθ and the force of friction
  C) mg sinθ and the normal reaction
  D) mg cosθ and the normal reaction
  Show Answer
  The correct answer is B .
• Question 1986: A conductor has a diameter of 1.00mm and length of 2.00m. If the resistance of the material is 0.1Ω, the resistivity is Options:
  A) 2.55 * 10⁵ Ωm
  B) 2.55 * 10³ Ωm
  C) 3.93 * 10^-6 Ωm
  D) 3.93 * 10^-8 Ωm
  Show Answer
  The correct answer is D .
• Question 1987:



  In the network shown above, determine the potential difference across the 5µF capacitor

  Options:
  A) 3V
  B) 6V
  C) 12V
  D) 18V
  Show Answer
  The correct answer is D .
• Question 1988:



  A force varying linearly with the distance acts on a body as shown above, The work done on the body by the force during the first 10m of motion is

  Options:
  A) 100J
  B) 150J
  C) 200J
  D) 300J
  E) 600J
  Show Answer
  The correct answer is A .
• Question 1989: In a tuned radio receiver R, L, C series circuit for resonance, the inductive and capacitive reactance X_L and X_C respectively are related as Options:
  A) X_L = X_C
  B) X_L = ¹/₂X_C
  C) X_L = ¹/_XC
  D) X_L = 2X_C
  Show Answer
  The correct answer is A .
• Question 1990:

  Which of the following thermometers measures temperature from the thermal radiation emitted by objects?

  Options:
  A) Pyrometer thermometer
  B) Platinum resistance thermometer
  C) Thermocouple thermometer
  D) Constant pressure gas thermometer
  Show Answer
  The correct answer is A .
