Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 1781:



  In the a.c circuit above, the current value is

  Options:
  A) 0.58 A
  B) 3.00 A
  C) 4.00 A
  D) 6.67 A
  Show Answer
  The correct answer is C .
• Question 1782: Induced emfs are best explained using Options:
  A) Ohm's law
  B) Faraday's law
  C) Colomb's law
  D) Lenz's law
  Show Answer
  The correct answer is D .
• Question 1783:



  The figure above shows a plot of angles of deviation through a glass prism when light is incident at θ degrees on the prism. The incident angle that produces the minimum deviation is

  Options:
  A) 20^o
  B) 18^o
  C) 35^o
  D) 25^o
  Show Answer
  The correct answer is D .
• Question 1784:

  A lorry accelerates uniformly in a straight line with acceleration of $4m{s}^{-}2$ and covers a distance of 250 m in a time interval of 10 s. How far will it travel in the next 10 s?

  Options:
  A) 650
  B) 900
  C) 800
  D) 250
  Show Answer
  The correct answer is A .
• Question 1785:

  A straight wire 15cm long, carrying a current of 6.0A is in a uniform field of 0.40T. What is the force on the wire when it is at right angle to the field

  Options:
  A) 0.46N
  B) 0.35N
  C) 0.36N
  D) 0,24N
  Show Answer
  The correct answer is C .
• Question 1786: A block and tackle pulley arrangement has 6 pulleys in which an effort of 50N supports a load of 200N, calculate the efficiency of the machine Options:
  A) 80.0%
  B) 76.6%
  C) 66.7%
  D) 60.7%
  Show Answer
  The correct answer is C .
• Question 1787:

  A boat at anchor is rocked by waves whose crest are 100m apart and whose velocity is 25ms^-1. At what interval does the wave crest reach the boat?

  Options:
  A) 2500.00s
  B) 75.00s
  C) 4.00s
  D) 0.25s
  Show Answer
  The correct answer is C .
• Question 1788: The hatch door of a submarine has an area of 0.5m². The specific gravity of sea water is 1.03. Assume that g = 10ms^-1,and neglect the atmospheric pressure. The force exerted by the sea water on the hatch door at a depth of 200m is Options:
  A) 1.03 x 10⁵N
  B) 1.03 x 10⁴Nm^-2
  C) 1.06 x 10⁵Nm^-2
  D) 2.06 x 10⁶N
  E) 1.03 x 10³N
  Show Answer
  The correct answer is E .
• Question 1789: Three electric cells each of e.m.f 1.5V and internal resistance of 1.0$\mathrm{\Omega }$ are connected in parallel across an external resistance of $\frac{2}{3}$$\mathrm{\Omega }$. Calculate the value of the current in the resistor Options:
  A) 0.5 A
  B) 0.9A
  C) 1.5A
  D) 4.5A
  Show Answer
  The correct answer is C .
• Question 1790:

  The lead-acid accumulator consists of

  Options:
  A) lead as the positive electrode
  B) lead acid as the negative electrode
  C) hydrochloric acid as the electrolyte
  D) tetraoxosulphate (vi) acid as the electrolyte
  Show Answer
  The correct answer is D .
