Physics is the science that studies the nature and properties of matter and energy. It covers topics like motion, heat, light, sound, electricity, magnetism, and the structure of atoms.

• Question 1671: A regular spacing or arrangement of atoms in a crystalline material is called Options:
  A) Orbit
  B) Lattice
  C) Atomic structure
  D) Energy level
  Show Answer
  The correct answer is B .
• Question 1672:

  When the temperature of a liquid increases,its surface tension

  Options:
  A) decreases
  B) increases
  C) remains constant
  D) increases then decreases
  Show Answer
  The correct answer is A .
• Question 1673:



  In the circuit above, the ammeter reads a current of 5.0 A when R = 8Ω and reads 7.0A when R = 5Ω. The value of the unknown resistance X is

  Options:
  A) 10.0Ω
  B) 7.5Ω
  C) 5.0Ω
  D) 2.5Ω
  Show Answer
  The correct answer is D .
• Question 1674:

  A tuning fork having a frequency of 312 Hz emits a wave which has a wavelength of 1.10 m. Calculate the velocity of sound

  Options:
  A) 312.0 ms${}^{-1}$
  B) 110.0 ms${}^{-1}$
  C) 343.2 ms${}^{-1}$
  D) 686.4 ms${}^{-1}$
  Show Answer
  The correct answer is C .
• Question 1675:



  The correct position for a fuse in the diagram above is

  Options:
  A) between P and Q
  B) Q
  C) S
  D) P
  Show Answer
  The correct answer is D .
• Question 1676: Which of the following does NOT describe the image formed by a plane mirror? Options:
  A) erect
  B) laterally inverted
  C) same distance from mirror as object
  D) magnified
  E) virtual
  Show Answer
  The correct answer is D .
• Question 1677: A lamp is rated 240V, 60W. The resistance of the filament is Options:
  A) 960$\mathrm{\Omega }$
  B) 16$\mathrm{\Omega }$
  C) 15$\mathrm{\Omega }$
  D) 4$\mathrm{\Omega }$
  Show Answer
  The correct answer is A .
• Question 1678:

  A 1000kg elevator is descending vertically with an acceleration of 1.0ms^-2, if the acceleration due to gravity is 10ms^-2, the tension in the suspending cable is

  Options:
  A) 1.0N
  B) 10.0N
  C) 9000.0N
  D) 11000N
  Show Answer
  The correct answer is C .
• Question 1679:

  Which of the following does NOT describe the Image formed by a plane minor?

  Options:
  A) Erect
  B) Laterally inverted
  C) Same distance from mirror as object
  D) Magnified
  Show Answer
  The correct answer is D .
• Question 1680: A quantity of ice at 10^oC is heated until the temperature of the heating vessel is 90^oC. Which of the following constants is NOT required to determine the quantity of heat supplied to the vessel? Options:
  A) specific heat capacity of ice
  B) specific heat capacity of water
  C) specific latent heat of fusion
  D) specific latent heat of vaporization
  Show Answer
  The correct answer is D .
